Product Details
Place of Origin: Guangdong, China
Brand Name: HAOXIANG
Certification: CE、ISO
Model Number: DSL2-7
Payment & Shipping Terms
Minimum Order Quantity: 1Unit
Packaging Details: Naked packing
Delivery Time: 7-15 Working days
Payment Terms: T/T
Supply Ability: 1500 Units per years
Lifting Mechanism: |
Hydraulic Lift |
Material: |
Steel |
Cabin Size: |
Customizable |
Platform Size: |
Customizable |
Usage: |
Loading And Unloading Goods |
Stroke Height: |
7m |
Lifting Mechanism: |
Hydraulic Lift |
Material: |
Steel |
Cabin Size: |
Customizable |
Platform Size: |
Customizable |
Usage: |
Loading And Unloading Goods |
Stroke Height: |
7m |
Attribute | Value |
---|---|
Lifting Mechanism | Hydraulic Lift |
Material | Steel |
Cabin Size | Customizable |
Platform Size | Customizable |
Usage | Loading and unloading goods |
Stroke Height | 7m |
Parameter | Specification |
---|---|
Product Name | Hydraulic Guide Rail Lift |
Usage | Loading And Unloading |
Rated Load | Up to 30 tons, Customizable |
Certification | CE/ISO |
Door | Manual/ Sliding/Swing |
Designed for transporting goods across building floors, commercial material lifts deliver reliable performance. Our variants serve hotels, logistics hubs, auto repair shops, and hypermarkets alike. What defines them is full customizability--voltage, table size, lifting height, capacity, and loading orientation can all be configured, and guardrail doors can be fitted as needed. Installation is straightforward, with slight demands on the site.
Specifications, sizes and colors can be customized according to customer requirements
Model | Rated load (kg) | Lifting stroke (mm) | Lowering height (mm) | Table size (mm) | Lifting time | Motor power (kw) |
---|---|---|---|---|---|---|
DSL1-3 | 1000 | 3000 | 100 | 2000×1800 | 6m/min | 3 |
DSL1-12 | 1000 | 12000 | 100 | 2500×2000 | 6m/min | 3 |
DSL2-4 | 2000 | 4000 | 150 | 2000×1800 | 6m/min | 4 |
DSL2-10 | 2000 | 10000 | 200 | 3000×3500 | 6m/min | 4 |
DSL3-5 | 3000 | 5000 | 150 | 3000×1800 | 6m/min | 5.5 |
DSL3-8 | 3000 | 8000 | 150 | 2000×1700 | 6m/min | 5.5 |
DSL4-5 | 4000 | 5000 | 250 | 3000×4000 | 6m/min | 7.5 |
DSL4-10 | 4000 | 10000 | 150 | 5000×3000 | 6m/min | 7.5 |
DSL5-6 | 5000 | 6000 | 400 | 5800×3000 | 6m/min | 11 |
DSL10-15 | 10000 | 15000 | 400 | 7000×5000 | 6m/min | 18.5 |
DSL15-9 | 15000 | 9000 | 800 | 8000×4000 | 6m/min | 30 |
DSL15-10 | 15000 | 10000 | 800 | 9000×4500 | 6m/min | 30 |
Situated in Xiaolan Township, Zhongshan City, Guangdong Haoxiang Machinery Manufacturing Co., Ltd. operates as a certified high-technology manufacturing enterprise specializing in hydraulic logistics solutions. With 30 million RMB registered capital and annual production value exceeding 100 million RMB, our company maintains a 21,500-square-meter modern production facility. Committed to developing ultra-safe, high-efficiency lifting systems, we prioritize creating innovative hydraulic lifting platforms that deliver reliable performance across logistics, warehousing, and industrial applications.
Equipped with advanced manufacturing technologies and rigorous quality control systems, we have established ourselves as an industry benchmark recognized for precision engineering and operational excellence. Our extensive service network includes 45 professional installation teams supporting over 40,000 client enterprises nationwide. We guarantee rapid-response services with 2-hour on-site support available in the Pearl River Delta region and 24-hour emergency response coverage across China, ensuring complete peace of mind for all equipment users.
